Description

We have been offering an advanced technology range of Hydraulic Rubber Moulding Press for different applications in varied sectors such as thermoset plastic, bakelite, thin metal, foam, resin, building materials forming, etc.

The Hydraulic Rubber Moulding Press is designed with PLC controller, auto control as well as manual control features to ensure maximum efficacy with high accuracy. The array is designed with automatic exhaust; automatic closing mould and curing calculate time. With automatic opening mould and delay alarm, the product provides the best performance. Every layer is equipped with high-quality mould slide rail with control the mould in or out options.

Features of Press – Single Station Hydraulic Rubber Moulding

• Available in simple design and high efficiency for maximum client satisfaction

• Designed with adjusted module, pressure compensation function and oil-way configuration

• Time as well as heating temperature can be easily adjusted as per the need

• Loaded with manual as well as semi-auto operation

  Hydraulic Rubber Moulding Press – Technical Specifications

  Model	Capacity (TON)	Ram Size (MM)	Daylight (MM)	Stroke Length (MM)	Platen / Bed Size (MM)	Electric Motor (HP)	Working Pressure (BAR)
  PRM – 50	50	120	250	200	300 x 300	5	210
  PRM – 100	100	180	350	250	400 x 300	7.5	210
  PRM – 150	150	250	400	300	500 x 400	7.5	210
  PRM – 200	200	275	450	350	600 x 500	10	210
  PRM – 250	250	350	450	350	700 x 600	15	210
  PRM – 300	300	350	500	400	800 x 600	20	210
  PRM – 400	400	400	550	450	800 x 650	20	210
  PRM – 500	500	400	600	500	900 x 700	20	210
  PRM – 600	600	500	650	500	900 x 800	30	210
  PRM – 800	800	650	750	600	1000 x 800	40	210
  PRM – 1000	1000	800	850	550	1200 x 1000	50	210

  Note:

  • Parrytech Hydraulic Rubber Moulding Press Available Up to 4000 Ton

  • Heavy Duty Presses Will Be Available

  • The Presses Will Be Manufactured As Per Customer Requirement
